Air Nozzles - Use Compressed Air Efficiently
to Blowoff, Clean, Dry or Cool |
| |
Engineered air nozzles provide a safe and efficient way to solve common industrial cleaning, cooling, drying or blowoff problems. |
| |
Applications
• Part
cleaning
• Chip
removal
• Part
drying
• Liquid
blowoff
• Part
cooling
• Material
conveying
• Part
ejection
• Fiber
conveying
• Air
assist |
Advantages
• Reduced
compressed air cost
• 10 dBA
average noise reduction
• Improved
blowoff performance
• Compact
• Meet OSHA
noise level requirements
• Meet OSHA
pressure requirements |
| |
|
How Air Nozzles Work
Air Nozzles use the coanda effect or small directed nozzles to amplify compressed airflow 25 times or more. As illustrated on the right, compressed air (black arrows) is ejected through a thin ring nozzle on the outer perimeter. As the air travels along the outer wall of the nozzle, surrounding air (blue arrows) is entrained into the stream. The center hole concentrates this airstream resulting in a high volume, high velocity blast of air at minimal consumption. The air is always ejected so it can vent safely should the nozzle end be blocked, well below OSHA dead ended pressure requirements. |
 |
|
|
MICRO AIR NOZZLE FOR PRECISION BLOWOFF
The Micro Air Nozzle is the smallest available. “Precision blowoff” provides optimum air entrainment for a directed high volume, high velocity airflow. The compact size permits mounting where space is limited. More |
 |
EFFICIENT AIR GUNS, COMFORTABLE GRIP
Safety Air Guns use engineered Air Nozzles to provide superior performance. Safe operation is assured along with low air consumption and noise level. Many styles and nozzles are offered. Extensions and Stay Set Hoses are available. More |
 |
NOZZLE CLUSTER, HIGHEST
BLOWING FORCE
Many blowoff, cleaning, cooling and drying applications require high force and extensive reach. Super Air Nozzle Clusters deliver up to 9.8 lbs of force. Three sizes for
handheld and stationary mounting are available. More |
 |
UNIQUE FLAT NOZZLE USES PATENTED TECHNOLOGY
The 2” Super Air Nozzle is a highly efficient, unique flat air nozzle. Using patented technology, a precise amount of air is released through the thin slot, across a flat surface. The result is a wide, forceful stream of high velocity, laminar airflow. Force and flow can be easily adjusted. More |
 |
DIRECTED BLAST OF AIR
Air Jets utilize the coanda effect (wall attachment of a high velocity fluid) to produce a vacuum on one end that pulls large volumes of room air through the unit. Both the outlet and inlet can be ducted for remote positioning. More |
 |
SUPER AIR NOZZLES
The aerodynamic design of Super Air Nozzles provide a high thrust, concentrated stream of high velocity airflow. The sound level is as low as 71 dBA with hard-hitting force up to 3.3 pounds. Super Air Nozzles meet OSHA noise and pressure requirements. More |
 |
A BREEZE TO A BLAST
These Safety Air Nozzles are adjustable, making them suitable for a wide variety of blowoff applications. This design allows you to “tune in” the force and flow to the application requirements, thereby minimizing air consumption. A micrometer like dial indicates the gap setting. More |
 |
| |
|
| |
|
|
To learn more about Air Nozzles, choose one of the following:
Super Air
Nozzle -
Award winning air nozzles provide the ultimate in efficiency and noise
reduction.
Mini Super
Air Nozzle - A smaller version of the original, award winning design for efficient air nozzles.
2" Super Air Nozzle - This Super Air Nozzle uses patented technology to provide greater efficiency and lower sound levels
Safety Air Nozzles - These nozzles eject a small amount of compressed air 360° around the outer ring that combines with the air ejected from the center hole to produce a high volume, high velocity blast of air. |
